成功案例
山西省平定县农村宅基地使用权限调查及数据入库工作地图制作项目
发布时间：
2025-04-11 10:18
浏览次数：
222
区域网1加密平差精度如下：
Parameter | X/Omega | Y/Phi | Z/Kappa | XY |
RMS Control | 0.034 | 0.039 | 0.029 | 0.037 |
RMS Check | 0.034 | 0.063 | 0.083 | 0.050 |
RMS Limits | 1.000 | 1.000 | 1.000 | |
Max Ground Residual | 0.076 | 0.065 | 0.060 | |
Residual Limits | 1.000 | 1.000 | 1.000 | |
Mean Std Dev Object | 0.020 | 0.022 | 0.042 | |
RMS Photo Position | ||||
RMS Photo Attitude | ||||
Mean Std Dev Photo Position | 0.037 | 0.037 | 0.032 | |
Mean Std Dev Photo Attitude | 0.007 | 0.007 | 0.003 | |
Sigma | 2.0 um | |||
Control Points Used | 13 | |||
Check Points Used | 3 | |||
区域网2加密平差精度如下：
Parameter | X/Omega | Y/Phi | Z/Kappa | XY |
RMS Control | 0.028 | 0.030 | 0.017 | 0.029 |
RMS Check | 0.015 | 0.016 | 0.027 | 0.016 |
RMS Limits | 1.000 | 1.000 | 1.000 | |
Max Ground Residual | 0.068 | 0.069 | 0.044 | |
Residual Limits | 1.000 | 1.000 | 1.000 | |
Mean Std Dev Object | 0.020 | 0.019 | 0.039 | |
RMS Photo Position | ||||
RMS Photo Attitude | ||||
Mean Std Dev Photo Position | 0.033 | 0.035 | 0.028 | |
Mean Std Dev Photo Attitude | 0.006 | 0.006 | 0.002 | |
Sigma | 1.9 um | |||
Control Points Used | 18 | |||
Check Points Used | 3 | |||
